Developing and simple hosting with K3s
Published on 2024/01/06
Introduction
K3s is a lightweight yet very effective Kubernetes open source distribution.
While Docker and the Kubernetes orchestrator are among the most popular hosting solutions for application components, two interesting questions often remain open:
- how to work locally as a developer: this is useful to set up, test and debug the deployment more efficiently than if working remotely, but also to leverage local computing resources
- how to orchestrate application containers in production environments where there is no managed Kubernetes solution, or no cost-effective one either
This article provides feedback for deploying and using K3s in the context of development but also simple production.
Installing K3s for development
Kubernetes control plane installation
Depending on your way of working and preference,
you can install K3s either directly on the development host if it is running Linux,
or on a separate Linux Virtual Machine that you will access remotely with kubectl.
Unless you want to test multi-nodes specific use-cases in development,
the default installation with all the components on a single node
is all what you need.
K3s installs the container runtime containerd for running Docker-compatible containers, and that is a strong system requirement. If you are already running Docker on the host, install K3s on a separate Virtual Machine, or configure the installer to use it.
When ready, connect to the target host and run:
# curl -sfL https://get.k3s.io | sh -
Depending on system and network resources, this single command will take a few dozens of seconds and deploy a fully operational Kubernetes cluster as detailed below.
It is worth mentioning that the resulting cluster will restart happily after a K3s host restart, making the solution convenient when the development environment is stopped.
That being said, this doesn't prevent obviously the application pods to take care of their data by themselves.
Analyzing the K3s architecture
Having a look at the architecture document, this simple deployment means that we run the K3s server components on the installed host, and there is no additional K3s agent node.
We find on this document the following familiar Kubernetes components:
- "
api-server" is the cluster API entry point; - "
scheduler" is responsible to allocate resources to the containers to be run; - "
controller-manager" is responsible to apply requested changes on the cluster; - "
kubelet" is an agent running on each node to control the state of containers; - "
kube-proxy" is responsible to configure network rules to enable secured network communication among the components and with external systems;
We also find the "kine" component that,
in this default installation,
enables the K3s server to store the cluster configuration and state
in a SQLite database, but could handle etcd as well.
What is specific to K3s is that those components are packaged and run
in a single Linux process, the k3s service on the previous schema,
making the use of CPU, memory and network resources as efficient as possible.
Other Kubernetes distributions
typically run them as individual containers and Linux system services.
# systemctl status k3s.service
● k3s.service - Lightweight Kubernetes
Loaded: loaded (/etc/systemd/system/k3s.service; enabled; preset: enabled)
Active: active (running) since Wed 2024-01-03 09:21:54 CET; 3h 10min ago
Docs: https://k3s.io
Main PID: 2570 (k3s-server)
Tasks: 213
Memory: 1.7G
CPU: 26min 24.955s
A few containers are also deployed for the control plane:
# kubectl get pods -n kube-system
NAME READY STATUS RESTARTS AGE
local-path-provisioner-84db5d44d9-72qfw 1/1 Running 0 4h50m
helm-install-traefik-crd-w7fs6 0/1 Completed 0 4h50m
coredns-6799fbcd5-bctpp 1/1 Running 0 4h50m
helm-install-traefik-6lmt2 0/1 Completed 1 4h50m
svclb-traefik-e23bb5a4-4zrcl 2/2 Running 0 4h47m
traefik-8c645c69c-xrrcr 1/1 Running 0 4h47m
metrics-server-67c658944b-rlrzk 1/1 Running 0 4h50m
Among those, Traefik is a reverse proxy and load balancer that in our case is also able to play the role of a Kubernetes Ingress Controller. Traefik can use an ACME provider such as Let's Encrypt to request and renew TLS certificates corresponding to the DNS of the hosted applications services as declared in Kubernetes Ingresses.
Switching from Docker to Containerd
If you chose to use the default container runtime installation of K3s, things are a little bit less easy than when using the Docker product that comes packaged with its full featured command line interface.
Here are some installation steps to be performed on the K3s server.
Introducing Nerdcrl
First thing is to install a user-friendly command line tool to work with containers.
This tool is open source too and is called Nerdctl.
You can find uses of ctr and crictl tools too,
and they are installed with K3s,
but they are meant
for low-level interactions with containers as explained
here.
A minimal installation is enough in the case K3s is already installed.
The rootless mode is not necessary either when you don't have specific security constraints.
So just download the
binary
and install it in the PATH environment
for instance /usr/local/bin.
Nerdctl must be configured to use the K3s containerd installation:
# vi /etc/nerdctl/nerdctl.toml
address = "/run/k3s/containerd/containerd.sock"
namespace = "k8s.io"
Let us test the installation:
# nerdctl ps | grep traefik
c0a135145594 docker.io/rancher/mirrored-library-traefik:2.10.5 "/entrypoint.sh --gl…" 3 minutes ago Up k8s://kube-system/traefik-6cbd94bb8d-pgsl6/traefik
# nerdctl images|grep traefik
rancher/mirrored-library-traefik 2.10.5 ca9c8fbe0010 2 days ago linux/amd64 147.9 MiB 41.1 MiB
rancher/mirrored-library-traefik <none> ca9c8fbe0010 2 days ago linux/amd64 147.9 MiB 41.1 MiB
An ansible role for doing that is available here.
Nerdctl provides a
CLI
mostly compatible with Docker's one, just change docker with nerdctl,
which makes the switch as smooth as possible.
You can control images and containers as usual.
You can even launch docker compose stacks.
But you cannot build new images yet.
Introducing BuildKit
Nerdctl is able to build docker images with the familiar nerdctl build sub-command
as soon as BuildKit is installed.
BuildKit is the new backend for building Docker images. It is also packaged with recent releases of Docker, so you may have already used it in this context. Compared to the legacy Docker builder, it provides much better performance through various optimizations.
Download BuildKit binaries from the project
releases
and install them in the PATH environment
for instance /usr/local/bin.
BuildKit must be configured to use the K3s containerd installation:
# vi /etc/buildkit/buildkitd.toml
[worker.oci]
enabled = false
[worker.containerd]
enabled = true
address = "/run/k3s/containerd/containerd.sock"
namespace = "k8s.io"
The buildkitd daemon must be installed as a systemd service:
# vi /etc/systemd/system/buildkit.service
[Unit]
Description=BuildKit
Documentation=https://github.com/moby/buildkit
[Service]
Type=simple
TimeoutStartSec=10
Restart=always
RestartSec=10
ExecStart=/usr/local/bin/buildkitd
[Install]
WantedBy=multi-user.target
# systemctl daemon-reload
# systemctl enable buildkit.service
# systemctl start buildkit.service
Let us test the installation:
# cat > Dockerfile <<EOF
from nginx
RUN echo "that's it" > message.txt
EOF
# nerdctl build -t nginx-custo:0.1 .
[+] Building 0.4s (6/6) FINISHED
=> [internal] load build definition from Dockerfile
...
=> => naming to docker.io/library/nginx-custo:0.1 0.0s
=> => unpacking to docker.io/library/nginx-custo:0.1 0.0s
An ansible role for deploying BuildKit as above is available here.
Now you are ready to use the nerdctl build subcommand for building new Docker images.
The images are available locally for direct use by Kubernetes Pod containers, so there is no need for a Docker images registry in this context.
Kubectl configuration
To access the K3s cluster with kubectl from a remote or non-root position
just copy the file /etc/rancher/k3s/k3s.yaml
into the local file $HOME/.kube/config,
then change the server url
server: https://127.0.0.1:6443
with the name of the K3s server
server: https://<k3s-server-name>:6443
Ready for development
The Kubernetes environment is now fully operational for the development activities:
- building container images
- deploying Kubernetes workloads as Pods using those images,
- deploying related resources such as services and ingresses,
- accessing hosted workloads through the Ingress Controller and other gateway services
As K3s is production-ready, can the previous kind of deployment be used for hosting production workloads?
Simple hosting for production
Introduction
Many deployment scenarios require a high level of availability. While K3s provides all the required features for supporting it, this is obviously not the case of this simple deployment, as there are those two main single points of failure:
- the server node for the K3S server and user-plane workloads
- the SQLite database for storing the cluster configuration and state
Anyway, high availability does not necessarily mean always available, and even this simple deployment can provide a very good availability level as soon as it is effectively backed with automatic deployment. And as the deployment is lightweight like we saw it, the recovery time can be pretty low. We could say that the lack of redundancy is compensated by the simplicity of what is to be deployed.
If we want to apply this solution for production workloads, we can either build the application container images on the K3s server using continuous deployment scripts, or, in order to improve the global reliability and availability, we can rather build those images using continuous integration scripts that push them in a registry from where they can be pulled at deployment time.
The following schema describes the deployment for both solutions, with a registry hosted as a Kubernetes Pod on the K3s cluster.
Two topics require some attention:
- configuring the Ingress Controller for HTTPS TLS termination and related ACME certificates
- configuring the registry for hosting on Kubernetes
They are detailed in the following sections.
Configure the Traefik Ingress Controller
We want to expose Web services and applications on internet using HTTPS. For this, corresponding services deploy a Kubernetes Ingress resource, which is handled by the Traefik Ingress Controller before being forwarded to the actual service. Traefik provides TLS termination but also implements HTTPS certificates generation and renewal using the ACME protocol.
The configuration of Traefik in the K3s context is a little bit convoluted but well documented here. This redirects to the Traefik Helm documentation.
In our case, we will provide the following configuration to K3s:
# vi /var/lib/rancher/k3s/server/manifests/traefik-config.yaml
apiVersion: helm.cattle.io/v1
kind: HelmChartConfig
metadata:
name: traefik
namespace: kube-system
spec:
valuesContent: |-
persistence:
enabled: true
logs:
general:
level: INFO
access:
enabled: true
ports:
web:
redirectTo:
port: websecure
websecure:
tls:
certResolver: leresolver
certResolvers:
leresolver:
storage: /data/acme.json
tlsChallenge: false
httpChallenge:
entryPoint: web
# systemctl restart k3s.service
This is a mix of Helm and Traefik-like configuration, from which the main information is:
- redirect HTTP traffic to HTTPS
- use the Let's Encrypt ACME resolver to generate certificates for the cluster ingresses
The ACME-generated certificates are kept persistent in a Kubernetes physical volume generated on local storage by the Helm template.
It is worth knowing that this configuration does not scale well: on a multi-node control plane, the distributed Traefik ingress controllers will each communicate with the ACME provider without coordination, eventually failing to get a correct certificate.
A collection of ansible roles for deploying K3s and the Traefik Ingress Controller as described previously are available here.
Deploy a Container Registry on K3s
The open source Container Registry distribution is lightweight and simple to configure for hosting.
We want to provide a secure transport with HTTPS and to authenticate accesses:
- the Traefik Ingress Controller will provide TLS termination for HTTPS, forwarding traffic over HTTP to the hosted registry, a thing that was detailed in the previous section,
- a second Traefik instance will play the role of reverse proxy, providing authentication and HTTP headers setting, as mentioned here
We could have for instance the containers registry deployed as a Pod and exposed with a Service:
apiVersion: v1
kind: Pod
metadata:
name: ctr-reg
labels:
app.kubernetes.io/name: ctr-reg
spec:
...
containers:
- name: ctr-reg
image: registry:2
ports:
- containerPort: 5000
volumeMounts:
- name: "ctr-vol"
mountPath: /var/lib/registry
- name: "ctr-vcf"
mountPath: /etc/docker/registry/config.yml
volumes:
...
restartPolicy: OnFailure
---
apiVersion: v1
kind: Service
metadata:
name: "ctr-reg"
spec:
selector:
app.kubernetes.io/name: "ctr-reg"
ports:
- name: "reg-port"
port: 5000
protocol: TCP
And deploy a Traefik reverse proxy for authentication and HTTP protocol settings:
apiVersion: v1
kind: Pod
metadata:
name: ctr-router
labels:
app.kubernetes.io/name: ctr-router
spec:
...
containers:
- name: ctr-router
image: "traefik:v2.10"
command: ["/usr/local/bin/traefik"]
args: ["--configFile=/traefik/static_config.yml"]
ports:
- containerPort: 5000
volumeMounts:
...
volumes:
...
restartPolicy: OnFailure
---
apiVersion: v1
kind: Service
metadata:
name: "ctr-router"
spec:
selector:
app.kubernetes.io/name: "ctr-router"
ports:
- name: "router-port"
port: 5000
protocol: TCP
---
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
name: "ctr-router"
spec:
rules:
- host: "<your DNS>"
http:
paths:
- path: /
pathType: Prefix
backend:
service:
name: "ctr-router"
port:
number: 5000
While the Traefik reverse proxy simply communicates over HTTP with the registry, it is necessary to tell the registry that the origin protocol is HTTPS.
Thus from /traefik/static_config.yml:
providers:
file:
filename: /traefik/dynamic_conf.yml
watch: true
entryPoints:
web:
address: ':5000'
to /traefik/dynamic_conf.yml:
http:
routers:
to-app:
rule: "PathPrefix(`/`)"
priority: 1
middlewares:
- basic-auth
- https-header
service: reg
middlewares:
"basic-auth":
basicAuth:
users:
- "<user>:$apr1$<password>"
https-header:
headers:
customRequestHeaders:
X-Forwarded-Proto: "https"
services:
"reg":
loadBalancer:
servers:
- url: "http://ctr-reg:5000"
A collection of ansible roles for deploying the Distribution registry as detailed above are available here.
Additional notes
When dealing with failure recovery, the cluster may have to be redeployed from scratch, including the hosted Pods. This require each hosted Pod to take the responsibility to backup its data in a safe place, and then to restore it at installation time. Various cloud storage solutions can be used for such a need.
Concerning the Let's Encrypt ACME provider, the number of certificates generated for a given DNS zone is limited in time. So repeated failure recoveries could lead to reach this limit, while this is very unlikely. More on this here.
Conclusion
Except if you want to deploy a Containers Registry, the deployment of a simple K3s cluster for development or for production as seen above is simple enough to be achieved manually. Build and deployment automation can reduce the time for failure recovery, but more often for infrastructure upgrade, and ansible roles and playbooks for doing that are available in the following git repository.
K3s is really a great solution for developing and for simple hosting on Kubernetes. I personally use it for both activities, and concerning the production, the K3s cluster is hosting, no talking about the control plane
- 5 web sites with low activity, totalling
- 17 pods
- 27 lightweight containers (using Apache, Traefik, Cabri and Python for APIs)
all running on a 2 vCores / 4 GB RAM Virtual Machine. I guess this can be called no bullshit Green IT, with all due respect to cows and bulls.
Such simple hosting can be of great interest for SOHO self-hosting.
Finally, such an article cannot be closed without sending a big thank you to all Kubernetes communities, providing real open source solutions with the support of so many individuals and often backed by fair companies. Such projects cannot succeed without them, and there are a lot of ways to support them.
